Texas Instruments UCC21540ADWKR
| Manufacturer | |
| Mfr. Part # | UCC21540ADWKR |
| EBEE Part # | E85216343 |
| Package | SOIC-14-300mil |
| Customer # | |
| Datasheet | |
| EDA Models | |
| ECCN | EAR99 |
| Description | SOIC-14-300mil Isolators - Gate Drivers ROHS |
This materials supports customized cables!
Learn more >>In Stock : Please Inquire
Please send RFQ , we will respond immediately.
Sales Unit: PieceFull Bag: 200
| Qty. | Unit Price | Ext. Price |
|---|---|---|
| 1+ | $1.5336 | $ 1.5336 |
| 10+ | $1.2613 | $ 12.6130 |
| 30+ | $1.1127 | $ 33.3810 |
| 100+ | $0.9425 | $ 94.2500 |
| 500+ | $0.8682 | $ 434.1000 |
| 1000+ | $0.8342 | $ 834.2000 |
Recommended For You
Specifications
2768products found.Show Similar| Type | Description | Select All |
|---|---|---|
| Category | Power Management (PMIC) ,Isolators - Gate Drivers | |
| Datasheet | Texas Instruments UCC21540ADWKR | |
| RoHS | ||
| Operating Temperature | -40℃~+125℃@(Ta) | |
| Quiescent Current | 2mA | |
| Number of Channels | 2 | |
| Voltage - Supply | 3V~5.5V;6V~18V | |
| load type | IGBT;MOSFET | |
| Driven Configuration | Low Side;High Side;Half-Bridge | |
| Rise Time | 16ns | |
| Fall Time | 12ns | |
| Isolation Voltage(Vrms) | 5700 | |
| CMTI(kV/us) | 100kV/us | |
| Current - Output High(IOH) | 4A | |
| Current - Output Low(IOL) | 6A | |
| Input Logic Level - Low | 0.8V~1.25V | |
| Input Logic Level - High | 1.6V~2V | |
| Propagation Delay(tpd) | 40ns;40ns |
