Manufacturer	HL
Mfr. Part #	2300
EBEE Part #	E823377920
Package	SOT-23
Customer #
Datasheet	HL 2300
EDA Models
ECCN	-
Description	20V 5.2A 21mΩ@4.5V,4A 700mV@250uA 1 N-Channel SOT-23 MOSFETs ROHS

Qty.	Unit Price	Ext. Price
50+	$0.0174	$ 0.8700
500+	$0.0137	$ 6.8500
3000+	$0.0116	$ 34.8000
6000+	$0.0105	$ 63.0000
24000+	$0.0093	$ 223.2000
51000+	$0.0087	$ 443.7000

Type	Description	Select All
Category	Transistors/Thyristors ,MOSFETs
Datasheet	HL 2300
RoHS
Operating Temperature	-
Type	1 N-Channel
Configuration	-
Drain Source Voltage (Vdss)	20V
Continuous Drain Current (Id)	5.2A
Drain Source On Resistance (RDS(on)@Vgs,Id)	21mΩ@4.5V,4A
Power Dissipation (Pd)	-
Gate Threshold Voltage (Vgs(th)@Id)	700mV@250uA
Reverse Transfer Capacitance (Crss@Vds)	-
Input Capacitance (Ciss@Vds)	-
Total Gate Charge (Qg@Vgs)	-
